Photo Gallery

UHV Flange
Titanium Rose
1/4" OD 304SS Tube .032 wall
304SS UHV Component
304SS Machine Baseplate
LS Swap Chevelle Intake
Custom Dual Transmission shifter for MLZ Garage
Ford 9in Mustang four link kit
Finished matte black Harley Dyna oil pan after TIG weld repair and paint, with no visible repair
Harley Dyna Aluminum Oil Pan, TIG Welded to a Factory Look
A torn cast aluminum oil pan from a Harley Dyna, TIG welded and refinished so it looks factory original, with no visible sign of the repair. Read more...
Classic Porsche 911 raised on a custom rolling steel chassis jig in the shop
Chassis Jig Designed from a 3D Scan: Classic Porsche 911
We scanned the underside of a classic Porsche 911, designed a chassis jig around it in CAD, and fabricated it from tube steel. Read more...
TIG-welded stainless downpipe on a Mitsubishi Evo with heat-tint coloring
TIG-Welded Downpipe on a Mitsubishi Evo
A custom TIG-welded downpipe made for a Mitsubishi Evo. Read more...
Custom stainless steel X-pipe with TIG welds showing heat-tint colors
Custom Stainless Exhaust, TIG Welded
A TIG-welded stainless X-pipe and a full custom exhaust under a car on the lift. Read more...
Custom fabricated aluminum center console with billet shifter and switch panel
Custom Aluminum Console with Billet Shifter
A fabricated aluminum center console with a billet shifter and a switch panel. Read more...
Custom TIG-welded aluminum intercooler piping routed through an engine bay
Aluminum Charge Piping and Engine Bay Fabrication
Custom TIG-welded aluminum intercooler piping and a fabricated aluminum engine bay panel. Read more...
Stainless steel tee fitting with a flange TIG welded on
TIG Weld Detail: Stainless Flange and Rolled Seam
Close-ups of a TIG-welded stainless tee and flange and a rolled seam weld. Read more...
Flat aluminum blank beside hand-hammered teardrop-shaped aluminum panels
Hand-Formed Aluminum Panels
Aluminum panels shaped by hand, from flat sheet to finished teardrop forms. Read more...
Close-up of stainless steel instrument tubing with compression fittings feeding a gray cast valve body, beside a welded stainless pipe elbow
304 Stainless Tube Drain Lines for a Nitrogen Generator System
1/2" 304 stainless tube drain lines, bent, fitted and routed for a nitrogen generator system at a food and beverage facility. Read more...
Finished weld repair on a CAT cast housing, blended and peened smooth where the flange meets the housing wall
CAT Housing Cast Crack Repair: Welded, Blended and Peened
A cracked CAT cast housing, ground out, welded, then blended and peened. Read more...
Black-coated custom steel bracket with a TIG weld along the center gusset
Fabricated Steel Bracket: Before and After Coating
A custom steel bracket with slotted mounts, shown bare and then finished in black. Read more...
Manually machined aluminum block with chamfered edges seated snugly inside a length of C-channel
Manual Machined Aluminum Block to Fit C-Channel
An aluminum block machined on a manual mill, sized and chamfered to seat snugly inside a length of C-channel. Read more...
